Step by step installation instructions for the Bravat Wall Mounted Brushed Gold Shower Set With Thermostatic Valve Mixer 3-Way Concealed

Bravat Wall Mount Brushed Gold Shower Set With Thermostatic Mixer Valve 3-Way Concealed The Bravat Brushed Gold Shower Set With Mixer Valve 3-Way Concealed Wall Mount is one of the most trendiest finishes across decor styles in the bathroom. It has a contemporary style with a beautiful Brushed Gold finish. Turn on the fun in your shower and experience the true feeling of rain, as well as SPA body massage spray, relieving fatigue and stress just by turning on the water in a high-pressure bathroom head shower with 360° 6 adjustable body spray jets and a hand shower. Bravat Brushed Gold Shower Valve Mixer 3-Way Concealed Wall Mounted Features: Brand Name: BathSelect Model Number: BS1064 Type: Shower Set & Shower Mixer Style: Contemporary Type: Fixed Support Type Surface Finish: Brushed Gold Installation Type: Wall Mount Number of Jets: Four Control Type: Single Holder Dual Control Size: 7.91"-11.85" (201-300mm) Surface Treatment: Polished Valve Core Material: Ceramic Bath Shower Type: In-Wall Shower Mixer Valve Type: Ceramic Valve Faucet Handle Material: Zinc Alloy Mixer Body Material: Brass Valve Included: Yes Embedment Depth: 2.16" (55mm) Valve Panel Dimension: 6.29"x6.29" (160x160mm) Connector: G1/2"B (Standard) BathSelect® Manufacturer Warranty Information Before you begin, please read the installation instructions below. Observe all local building and safety codes. Unpack and inspect the product for any shipping damages. If you find damages, do not install. Please note all showers must be installed by a professional and certified plumber otherwise warranty might be voided.

shower

Shower

	Shower Head Parts Included: Wall Mounting Arm Locking nut Wall trim Shower arm Showerhead Fixing screws and wall plugs (not shown)

Step 1:		Step 2:		Step 3:
Wall Mount Round Showerhead	Showerhead		Showerhead
Wall Mount Round Showerhead
Step 4:		Step 5:		Step 6:
Wall Mount Round Showerhead

Hand-Held Shower Installation Instructions

Step 1:		Step 2:		Step 3 & 4:
	Hand Held Shower		Hand Held Shower
Handheld Shower		Handheld Shower		Handheld Shower
Step 5:		Step 6 & 7:		Step 8:

Mixer Installation Instructions

1. Gather All Parts

2. Hole Locations For Wall Mount

Remove Front Cover (A) from Wall Mount (B). Use Wall Mount Screw Holes (C) to place the desired location. Using a punch or awl, tap the screw hole locations.
Holes must be vertically aligned.

3. Anchor Installation

Drill two 1/4” dia. Holes (A). If installing into a studs drill two 1/8” dia. holes and do not use Anchors (B). Insert Anchors (B) into Holes (A) and tap flush with the wall.

4. Wall Mount Installation

Place Wall Mount (A) into wall and inset Mounting Screws (B) through Wall Mount Holes (C) and tighten until Wall Mount (A) is flush with the wall.
Do Not Over Tighten! Insert Front Cover (D) into Wall Mount (A)

5. Drop Elbow & Hose Installation

Apply PTFE plumbers tape on both ends of Pipe Nipple (A) (not included). Screw Pipe Nipple (A) into the elbow inside the wall.
The Pipe Nipple (A) is to project 1/4” – 3/4” from the finished wall. Screw Drop Elbow (B) onto Pipe Nipple (A) and tighten until Drop Elbow (B) is property positioned and flush to the finished wall.

Place Rubber Seal (C) inside Hex Hose Fitting (D). Connect Hex Hose Fitting (D) into Drop Elbow Outlet (E) by turning Hex Hose Fitting (D).

6. Unit Startup

Turn on hot and cold water supplies, and check all connections for leaks.

7. Final Flushing

For final flushing, turn the valve on and allow water to run through the Hose (A) for several minutes.
Allow water to run for several minutes until all foreign matter clears the line.

8. Shower Arm Installation

Place Rubber Seal (A) inside Tapered Hose Fitting (B). Conned Hand Shower (C) to Hose (D) by turning Tapered Hose Fitting (B ) clockwise.
Warning: Make sure Hand Shower (C) is securely tightened to Hose (D).

Shower Body Jets Installation Instructions

Step 1:		Step 2:		Step 3:
	Body Sprays		Body Sprays
Set the decorative cover on the body jet.		Roll the raw material belt in the thread screws.		Use a wrench to tighten 6 body jets on the water outlet holes in a clockwise direction.

Thermostatic Valve Mixer Installation Instructions

Mixer Installation Instructions

Step 1:	Mixer	Step 2:
Close the stops. Cut the plaster shield so that it extends ¹⁄₁₆" - ⅛" from the finished wall surface.		Seal the wall around the plaster shield with a waterproof sealant. Remove the flush insert and the flush insert seals.
Thermostatic Valve Mixer Installation Instructions
Step 3:		Step 4:
Install the function block. Install and tighten the function block screws.		Measure the distance from the front of the plaster shield to one of the screw-in flanges ("X").
Thermostatic Valve Mixer Installation Instructions
Step 5:		Step 6:
Add ½" to this measurement. Cut each screw so that it is X + ½" long.		Open the stops. Install the carrier plate so that the notch is at the bottom.
Thermostatic Valve Mixer Installation Instructions
Step 7:		Step 8:
Slide on the thermostatic mixer sleeve so that the indexing mark is at the 12:00 position. Screw on the volume control sleeve. Install the escutcheon.		Place a dab of waterproof sealant at each grout joint.
Thermostatic Valve Mixer Installation Instructions
Step 9:		Step 10:
Lubricate the adapter stems with a small amount of white plumber's grease. Install the handle adapters and screws. Tighten the screws.		Install the volume control handle. Tighten the screw. Install the thermostatic mixer handle so that the safety stop override button is at the 9:00 position. Tighten the handle screw using a 2.5 mm Allen wrench.
Thermostatic Valve Mixer Installation Instructions

Thermostatic Valve Mixer Installation Instructions
