BathSelect Dark Oil Rubbed Bronze Infrared Automatic Electronic Commercial Faucet with Manual Soap Dispenser
Sensor faucet complete motion detection operation.
Sensitive Sensor with Infrared AI Smart-Chip
Factory set to 30-second Auto Shutoff (can be adjusted).
Water Pressure: 0.5 - 7.0 KGS/cm, 10 - 125 psi
Solid Brass Construction, Dark Oil Rubbed Bronze
Installation made easy with simplified instructions
Water resistant solenoid enclosure
Advanced energy saving design for long lasting battery life
Comes complete with Hoses & Accessories
Power Supply: AC110V And DC6V (batteries not included)
AC/DC power option.
ADA Compliant.
Can be installed in new or retrofit applications.
Durable Vandal-Resistant Brass Body;
Ideal for commercial use applications in public restrooms, restaurants, office building, public facilities, hospitals.
Fits all standard US plumbing.
Intelligent: with its micro-computer controlling its action,
The faucet will self adjust best detection zone as per the color and shape of lavatory
Flashing light indicator; a diagnostic indicators for power up, low battery, and solenoid function.
Meaning of the codes are described in the installation instructions.
Convenient to maintain; with built-in strainer to prevent sundries from entering the solenoid valve and the strainer is easy to clean
Faucet can be mounted to any sink surface.
Batteries life 8,000 cycles per month and with enough water pressure is approx 5 year service life of the batteries.
Adjustable sensing range; while the factory range is set about 4"to 5"from the sensor, it can be adjusted.
Usage: Commercial / Residential
Diameter of inlet pipe:
DN15
Diameter of outlet pipe:
DN15
Water Pressure:
0.05Mpa - 0.7Mpa
Power and Voltage:
DC.6V, AC.220V - 50/60Hz
Power Consumption:
0.5MW, <2W
Detection Zone:
Factory set 25cm/10" (based on standard inductive board)
Ambient Temperature:
1 - 45 ℃ / 33.8 -113 °F
Degree of protection by enclosure:
1P56
The Bathselect Dark Oil Rubbed Bronze Commercial Infrared Automatic Electronic Sensor Activated Touchless Faucet with Manual Soap Dispenser
This sensor faucet brings a new element of design and cost-effectiveness into every bathroom it is installed. The cylindrical base, the infrared sensor, the elegant curve and the dark oil rubbed gold finish exudes a stylish and contemporary appeal that is perfect for the modern bathroom. Aside from the voguish design, the Bathselect Infrared Electronic Faucet is built with solid brass to ensure its longevity - which is why the manufacturer confidently packs it with a ten years warranty. The infrared sensor is sure to work all the time, releasing water only if there is an object within its range and automatically shutting water flow after preset time. This greatly decreases the amount of water wasted from leaving the tap on. The infrared sensor battery is guaranteed to work up to three years. The energy saving architecture of this electronic sensor faucet ensures you will be able to enjoy this touch-free electronic faucet for years and years to come. Minimize waste of water, by using the automatic faucet. Immediately reduces water waste by eliminating unnecessary and unattended water flow. Uses 4AA Alkaline Batteries (purchase separately).Water Pressure: 0.5 - 7.0 KGS/cm, 10-125 psi.Ideal for commercial use applications in public restrooms, restaurants, office building, public facilities, hospitals. Fits all standard US plumbing. Touchless faucet integrates low-flow control and auto shutoff for water conservation compliance.Hands-Free Faucet Set — manual soap dispenser supports bulk-fill programs common in institutional maintenance.
Bravat Automatic Sensor Faucet water-saving; hygienic; automatically opens and closes
to free hands - no touch, avoid bacteria mutual infections!
A great addition to powder room; kids bathroom, hotels, restaurants, public places, government facilities...!
This Sensor Faucet Applications; Residential, Commercial use & ADA
This faucet is shipped complete. ANSI A112.18.1M CSA Standard B125, 2.2 U.S.
GPM Complies with NSF Standard 61, Section 9
Flow Preventers Stainless Steel Hoses Mounting Hardware Batteries Pre-installed
All the hardware necessary for satisfactory installation
Specifications and Dimensions
Spout: Solid Brass Power: 4 (AA) Alkaline
Batteries or AC Adapter
Battery life expectancy: 250,000 cycles
Solenoid valve: 6 Volt magnet latching
Working Water Pressure: 1 PSI -100 PSI
Supply Inlet Size: 1/2” NPT Male
Water Temperature Control;
check
Options for temperature control sensor faucets
Built-in Pop-Up Drain
Rod: N/A
Sensor type and Location: Active Infrared, Neck mount Sensor
Microprocessor: Digital,
Pug And Play Sensing Range: 2” to 6”
Response Time: 0.3 Second
Shut-Off Delay Time: 2 Seconds
Anti vandalism maximum Running Time: 60 Seconds
Particle filter size: 50
Mesh Aerator: 2.2 GPM Standard
Features
We're available to provide assistance and support for your inquires!
Featured
categories
COMMERCIAL SENSOR LINE
BathSelect™
Commercial infrared touchless faucet with solid brass construction,
adjustable sensing, AC/DC power and four coordinated finish options.
✥
Sensor Calibration Procedure?
+
Complete sensor commissioning after the basin,
countertop and surrounding accessories are installed.
The factory sensing position is approximately
4 to 5 inches and may be adjusted to suit the
final lavatory geometry.
◇
Hydraulic Checks During Installation?
+
Flush the supply piping before final connection,
verify the DN15 inlet and outlet connections,
inspect the built-in strainer for debris and
confirm unrestricted water delivery before
commissioning the electronic valve.
◯
Flow Rate Verification?
+
The extended specification identifies a
2.2 GPM standard mesh aerator. If output becomes
restricted, inspect the aerator, 50-mesh filtration,
dynamic inlet pressure and supply connections.
↻
Continuous Water Flow Diagnostics?
+
Clean the infrared sensor area, remove reflective
objects from the sensing field and inspect the
6-volt magnet-latching solenoid for contamination
or incomplete seating. Maximum continuous operation
is approximately 60 seconds.
⌁
Sensor Detection Range?
+
The active infrared sensor uses digital
microprocessor control with an adjustable range
of approximately 2 to 6 inches. The primary
product data also lists a factory setting around
4 to 5 inches.
⌂
Operating Water Pressure?
+
BathSelect lists approximately 10 to 125 PSI in
the primary specifications, while the extended
technical information also identifies approximately
1 to 100 PSI working pressure.
⚡
Power Supply Options?
+
The faucet supports AC and battery operation.
BathSelect lists AC110V and DC6V capability,
while the extended technical specification
references four AA alkaline batteries or an
AC adapter.
⌕
Routine Maintenance Requirements?
+
Periodically clean the infrared sensor and aerator,
inspect the built-in strainer and 50-mesh filter,
remove mineral buildup and verify reliable solenoid
opening and complete automatic shutoff.
‹
›
Dark Oil Rubbed Bronze
♧
2.2 GPM
Standard Aerator
◇
Solid Brass
Commercial Construction
⌁
2–6 Inches
Adjustable Sensor
⚙
AC / DC
Dual Power Option
◇
250K Cycles
Battery Expectancy
