How to install an oil rubbed bronze shower set

Bravat Wall Mount Dark Oil Rubbed Bronze Shower Set With Thermostatic Mixer ValveConcealed

The Bravat Dark Oil Rubbed Bronze Shower Set With Mixer Valve Concealed Wall Mount is one of the most trendiest finishes across decor styles in the bathroom. It has a contemporary style with a beautiful Dark Oil Rubbed Bronze finish. Turn on the fun in your shower and experience the true feeling of rain, as well as SPA body massage spray, relieving fatigue and stress just by turning on the water in a high-pressure bathroom head shower with 360° 6 adjustable body spray jets and a hand shower.
Bravat Dark Oil Rubbed Bronze Shower Mixer Valve Concealed Wall Mounted Features:
  • Brand Name: BathSelect
  • Model Number: BS1056
  • Type: Shower Set & Shower Mixer
  • Style: Contemporary
  • Type: Fixed Support Type
  • Surface Finish: Dark Oil Rubbed Bronze
  • Installation Type: Wall Mount
  • Control Type: Single Holder Dual Control
  • Size: 7.91"-11.85" (201-300mm)
  • Surface Treatment: Polished
  • Valve Core Material: Ceramic
  • Bath Shower Type: In-Wall Shower Mixer
  • Valve Type: Ceramic Valve
  • Faucet Handle Material: Zinc Alloy
  • Mixer Body Material: Brass
  • Valve Included: Yes
  • Embedment Depth: 2.16" (55mm)
  • Valve Panel Dimension: 6.29"x6.29" (160x160mm)
  • Connector: G1/2"B (Standard)
  • Bravat Wall Mount Dark Oil Rubbed Bronze Shower Set With Thermostatic Valve Mixer Concealed
    BathSelect® Manufacturer Warranty Information

    • Before you begin, please read the installation instructions below. Observe all local building and safety codes.
    • Unpack and inspect the product for any shipping damages. If you find damages, do not install.
    • Please note all showers must be installed by a professional and certified plumber otherwise warranty may be voided
    shower shower

    Shower Head Installation

    shower Shower Head Parts Included:
    • Wall Mounting Arm
    • Locking nut
    • Wall trim
    • Shower arm
    • Showerhead
    • Fixing screws and wall plugs (not shown)

    Step 1

    Step 2

    Step 3

    Step 4

    Step 5

    Step 6

    1. Remove the old shower head by using the channel lock pliers or monkey wrench. Be sure to turn the pliers counter-clockwise to loosen the old shower head. (Tip: Right is tight, left is loose.)
    2. Remove the shower arm by turning it by hand counter-clockwise. Make sure you remember to apply putty or tape to the new arm. (Tip: Using teflon tape is less messy)
    3. Apply teflon tape to the threading of the shower arm by wrapping it around the threads, go all the way around 3 or 4 times depending on the quality of the Teflon tape.
    4. Install the new shower arm by going clockwise by hand until it is tight, then put painters tape around the arm and tighten the arm with the channel lock or monkey wrench.
    5. Place Teflon tape around the threads on the shower head and then place the shower head onto the shower arm by turning the shower head clockwise after the shower arm is already in the wall.

    Thermostatic Mixer Valve

    Step 1

    mixer Step 2

    mixer Step 3

    1) Fix the shower valve into the wall with screws. Use a level to ensure that the valve is straight and level. (Important: Flush the water supply pipes to remove any dirt and debris before installing the valve body)
    2) Wrap Teflon tape around the pipe thread. Connect hot and cold water supply lines and all the in-wall pipes(not included) as desired to the valve. Turn on the water supply and open the cartridge to check for leaks. Then, put on the protective cover.
    3) Remove the protective cover when the wall finished wall is completed. Install escutcheon onto the shower valve and press it against the finished wall. Then, install the handle and diverter knob to the valve and tighten set screws with the Allen key and put on the indication button.

    Hand-Held Shower Installation Instructions

    Step 1

    shower Step 2

    Step 3

    Step 4
