The Brasília Oil Rubbed Bronze with Gold Shower Set Hand Shower & Faucet Installation

Brasília Oil Rubbed Bronze with Gold Shower Set Hand Shower & Faucet

The Brasília Oil Rubbed Bronze with Gold Shower Set Hand Shower & Faucet is a beautiful reminder of times long passed. This Shower Set combination of oil rubbed bronze and gold Finish, together with the sophisticated antique design, make it the perfect choice for modern bathrooms that aim for a special style. Brasília Shower Set is wall-mount, with a round shower head and a handheld a shower for convenience. The material is overall brass, while the valve core material is ceramic for best performance and long-lasting life time. It comes complete with accessories and installation instructions.

Brasília Oil Rubbed Bronze with Gold Shower Set Hand Shower & Faucet Features:

Type: Shower Set
Finish: Oil Rubbed Bronze & Gold
Number of Handle : One Handle
Showerhead Dimension: 8 inch
Height : (47.2")
Installation distance : 6 inch center to center
Hole center distance on the wall: (5.90")15cm
Valve Type: Ceramic Valve
Shower Set Material: Brass
Model Number: BS17AB

BathSelect® Manufacturer Warranty Information

Brasília Oil Rubbed Bronze with old Shower Set with Hand Shower Installation Instructions

1. Brass Adapter
2. Faucet body

3. Washers
4. Diverter
5. Shower bar
6. Hand shower holder
7. Shower bar bracket
8. Shower bar
9. Mounting base
10. Decoration cover
11. Rain shower head
12. Handheld shower

Step 1: Connect the brass adapter provided to the water supply line.

Step 2: Adjust lever and distance to fit the faucet body.

Step 3: Turn the water valve on for a while to let the dust and impurities out.

Step 4: Assemble the shower set.

Step 5: Place a pre-assembled shower in the wall to find the proper position and then mark the mounting hole that needs to be drilled.

Step 6: Drill a hole for the upper part shower bar bracket, screw it.

Step 7: Place the decoration cover to the brass adapters.

Step 8: Install the pre-assembled shower to the connections.

Step 9: Connect shower hose, handheld shower, and rain shower head.
