Romo Automatic Wall Mount Commercial Hands Free Motion Sensor Faucet in Oil Rubbed Bronze Finish
- Sensor faucet complete motion detection operation.
- Commercial use.
- Sensitive Sensor with Infrared AI Smart-Chip
- Factory set to 30-second Auto Shutoff (can be adjusted).
- Solid Brass Construction, Dark Oil Rubbed Bronze Finish
- Installation made easy with simplified instructions
- Water resistant solenoid enclosure
- Advanced energy saving design for long lasting battery life
- Comes complete with Hoses & Accessories
- Power Supply: AC110V And DC6V (batteries not included)
- AC/DC power option.
- ADA Compliant.
- Can be installed in new or retrofit applications.
- Touchless operation; specifically designed for optimal performance in various commercial use applications, making it ideal for public restrooms, restaurants, office buildings, public facilities and hospitals. Fits all standard US plumbing.
|
|
Wall Mount Sensor Faucet Details
- Type: Motion Sensor Faucet
- Protection Degree: IP56
- Brand Name: BathSelect®
- Model Number: BST-9021
- Feature: Sense Faucets, Electric Faucets
- Surface Treatment: Matt Finish Dark Oil Rubbed Bronze
- Faucet Mount: Single Hole Installation
- Type: Wall Mount
- Number of Handles: automatic
- Style: Contemporary
- Valve Core Material: Brass
- Material: 304 stainless steel
- solenoid valve: 6V magnet latching
- Response time: 0.3second
- Shutt-off delay time: 60 seconds
- Sensor type: Active Electronic infrared sensor
- Water Pressure: 0.05~0.8Mpa
- Dia of pipes: G1/2'' (DN15)
- Power and Voltage: DC.6V (4pcs AA batteries)
- Battery life expectancy: 150, 000 cycles
Reduces the transfer of germs by preventing cross-contamination and re-contamination of germs and bacteria by not touching the faucets or handles. Cut down on water usage by minimizing waste of water while soaping, lathering, scrubbing, and drying hands by eliminating unnecessary and unattended water flow.
Sensor Activated Faucet Special Features:
- Durable Vandal-Resistant Brass Body; Ideal for commercial high traffic use applications
- Intelligent: with its micro-computer controlling its action, the faucet will self-adjust its best detection zone as per the color and shape of the lavatory
- Flashing light indicator; a diagnostic indicator for power up, low battery, and solenoid function.
- The meaning of the codes is described in the installation instructions.
- Convenient to maintain; with a built-in strainer to prevent sundries from entering the solenoid valve and the strainer is easy to clean
- The faucet can be mounted to any sink surface.
- ADA Complaint
- The battery's life is 8,000 cycles per month and with enough water pressure is approx 5 years service life of the batteries.
- Adjustable sensing range; while the factory range is set about 4"to 5" from the sensor, it can be adjusted.
- Diameter of inlet pipe: DN15
- Diameter of outlet pipe: DN15
- Water Pressure: 0.05Mpa - 0.7Mpa
- Power and Voltage: DC.6V AC.220V - 50/60Hz
- Power Consumption: 0.5MW <2W
- Detection Zone: Factory set 25cm/10" (based on standard inductive board)
- Ambient Temperature: 1 - 45 ℃ / 33.8 -113 °F
- Degree of protection by enclosure: 1P56
The Wall Mount Commercial Sensor Activated Touchless Faucet- Oil Rubbed Bronze Finish
|
Commercial Wall-Mount Sensor Faucet; Designed for space-efficient installation with controlled discharge and consistent sensing performance. Minimize waste of water, by using the automatic faucet. Immediately reduces water waste by eliminating unnecessary and unattended water flow.Ideal for commercial use applications in public restrooms, restaurants, office building, public facilities, hospitals. Fits all standard US plumbing.Fits all standard US plumbing.Uses 4AA Alkaline Batteries (purchase separately).Water Pressure: 0.5 - 7.0 KGS/cm, 10-125 psi.
|
Trio Automatic Sensor Faucet water-saving; hygienic; automatically opens and closes
to free hands - no touch, avoid bacteria mutual infections!
A great addition to powder room; kids bathroom, hotels, restaurants, public places, government facilities...!
- This Sensor Faucet Applications; Residential, Commercial use & ADA
- This faucet is shipped complete. ANSI A112.18.1M CSA Standard B125, 2.2 U.S.
- GPM Complies with NSF Standard 61, Section 9
- Flow Preventers Stainless Steel Hoses Mounting Hardware Batteries Pre-installed
- All the hardware necessary for satisfactory installation
- Specifications and Dimensions
- Spout: Chrome Plated Solid Brass Power: 4 (AA) Alkaline
- Batteries or AC Adapter
- Battery life expectancy: 250,000 cycles Solenoid valve: 6 Volt magnet latching
- Working Water Pressure: 1 PSI -100 PSI
- Supply Inlet Size: 1/2” NPT Male
- Water Temperature Control;
check
Options for temperature control sensor faucets
- Built-in Pop-Up Drain
- Rod: N/A
- Sensor type and Location: Active Infrared, Neck mount Sensor
- Microprocessor: Digital, Pug And Play Sensing Range: 2” to 6”
- Response Time: 0.3 Second
- Shut-Off Delay Time: 2 Seconds
- Anti vandalism maximum Running Time: 60 Seconds
- Particle filter size: 50
- Mesh Aerator: 2.2 GPM Standard
|
|
|
 |
|
 |
|
|
|
 |
|
 |
|
Features
We're available to provide assistance and support for your inquiries!
Featured
categories
Romo Wall Mount Commercial Sensor Faucet Oil Rubbed Bronze FAQ
Wall-Mount Geometry, Infrared Control & Concealed Service Access
This oil rubbed bronze commercial faucet combines wall-mounted installation, automatic infrared activation, electronically controlled water delivery, and durable construction for high-use wash stations.
Why is spout projection especially important with the wall-mounted Romo faucet?
The outlet must project far enough over the basin to place the water stream inside the usable wash zone without excessive backsplash. Correct rough-in positioning also keeps the sensor aligned with the user's natural hand position.
How does the faucet stop water after a user moves away?
The infrared controller continuously monitors its active sensing field. When hands are no longer detected, the control signal changes and the solenoid valve closes automatically, ending water delivery without requiring physical contact.
What should be established before the finished wall is closed?
Installers should verify supply routing, valve position, sensor and power connections, finished-wall thickness, spout centerline, and basin relationship during rough-in. Correct coordination prevents the trim from sitting too deep or projecting incorrectly after finishing.
Which concealed parts should remain reachable for future servicing?
Access should be maintained to the solenoid valve, inlet filtration, electrical connections, sensor controls, and water-supply fittings. A planned service route allows maintenance without unnecessarily removing tile or other finished wall materials.
|
|
|
|
|
|
|
