Melo Rainfall Massage Shower Set Installation
Melo Rainfall Massage Shower Set
The Ultimate Bath Showering Experience can experience the true feeling of rain, as well as SPA body massage spray, relieving fatigue and stress. It is your best choice, a choice to enjoy life. The elderly, children and pregnant women can use. A sleek gleaming finish covers the entire fixture making it beautiful too look at as well as easy to clean. The handheld shower is just as great, with solid water pressure and well-designed grip for better handling. This is constructed from strong and durable brass and chrome finished, undertakes to provide optimal shower terminals for users and offers a serious of thoughtful designed of a Showerhead, accessories, and bath safety products for residential. Full extra thick stainless steel and brass construction tube ensures durability, heavy-duty and long life use.
Melo Rainfall Massage Shower Set Features:
- Shower Set Height: 65"
- Double locked stainless steel shower hose 1.5m.
- Brass Valve Water pressure balance control
- Comes with 64-inch chrome-plated brass hose
- Standard plumbing connection-Shower Panel Unit is pre-plumbed
- All functions work independently to ensure the proper water pressure
- The minimum pressure required is 29 psi and maximum pressure required 72.7 psi.
- Ceramic Disc Technology
- The recommended pressure for best performance 2 to 75 psi
- Easy installation, comes with all standard accessories.
- The flow rate is 2.5 GPM
|
|

BathSelect® Manufacturer Warranty Information
Installation Manual For Melo Shower Set
|
|
1. Brass Adapter
2. Faucet body
3. Washers
4. Diverter
5. Shower bar
6. Hand shower holder
7. Shower bar bracket
8. Shower bar
9. Mounting base
10. Decoration cover
11. Rain shower head
12. Handheld shower
Step 1: Connect the brass adapter provided to the water supply line.
Step 2: Adjust lever and distance to fit the faucet body.
Step 3: Turn the water valve on for a while to let the dust and impurities out.
Step 4: Assemble the shower set.
Step 5: Place a pre-assembled shower in the wall to find the proper position and then mark the mounting hole that needs to be drilled.
Step 6: Drill a hole for the upper part shower bar bracket, screw it.
Step 7: Place the decoration cover to the brass adapters.
Step 8: Install the pre-assembled shower to the connections.
Step 9: Connect shower hose, handheld shower, and rain shower head.
|
