Installation Instructions for Leonardo LED Light Shower Head with Built-in Mixer


Leonardo LED Light Shower Head with Built-in Mixer

The Leonardo Special Design, High-Quality LED Shower System, Rainfall Shower Head, and Mixer Brass made with Chrome Finish Lights are powered by water pressure. Turn on the fun in your shower just by turning on the water, the LED lights will automatically light up and set the mood. They will even change colors automatically based on the water temperature. All this with no batteries, everything is self-powered by a built-in dynamo that takes advantage of the water pressure to create the energy to light the bulbs. When water temperature is ≤89 °F (≤32 °C), Green color will show automatically; When water temperature is between 97 to 107 °F (36-42 °C), Blue color will show automatically; When water temperature is between 109 to 122 °F (43-50 °C), Red color will show automatically; When water temperature is above 122 °F (>50 °C), Red color will flash immediately. No electrical wiring needed changes color as temperature change

LED Shower Head Shower Set Features:

  • Brand Name: BathSelect
  • Model Number: BSHM-LED6109
  • Finish: Chrome
  • High quality LED Shower Head
  • Multi-function control valve: Solid Brass
  • Shower Arm: Solid Brass Shower Arm and Flange
  • Shower Head Material: Solid Brass
  • Drip Free Ceramic disc cartridge for smooth and long-lasting operation
  • Easy to clean for non-tarnish life shine
  • Self-powered by Water. No Battery nor Electricity needed.
  • This is a complete shower set with all the installation accessories.
  • Flow Rate: 2.5 GPM
Leonardo LED Light Shower Head with Built in Mixer Leonardo LED Light Shower Head with Built in Mixer

Leonardo LED Light Shower Head with Built in Mixer
BathSelect® Manufacturer Warranty Information
  • Before you begin, please read the installation instructions below. Observe all local building and safety codes.
  • Unpack and inspect the product for any shipping damages. If you find damages, do not install.
  • Please note all showers must be installed by a professional and certified plumber otherwise warranty might be voided




Shower Head Installation





No tools required, ½ connector fits standard sized shower plumbing.


  1. Use your hands counter clockwise to unscrew the old showerhead and removed it.
  2. Take out the showerhead, make sure the shower filter is placed in the connector.
  3. Ensure the showerhead full horizontal alignment wall mounted shower arm thread.
  4. Use your hands clockwise to tighten showerhead.


Shower Mixer Installation



Wall-mounted-shower-head
1. Install the valve body. Wrap the threaded portion of the joints in Teflon tape and connect the water inlet and outlet.


  1. When the finished wall is complete, remove the protective cover.
  1. Install the escutcheon, and handle it. Tighten the set screw with an Allen wrench to secure.
  1. Attach the shower arm escutcheon to the shower arm. Wrap the threaded portions of the shower arm with Teflon tape and connect the arm to the shower inlet. Adjust the direction of the water flow as needed. Attach the rainfall showerhead to the shower arm.
