Installation Instructions For Leonardo Gold Finish Rainfall Waterfall Shower System Set

Leonardo Gold Finish Rainfall Waterfall Thermostatic Shower System Set

The Leonardo Gold Finish Rainfall Thermostatic Shower System Set will turn your shower into one that looks exceptional. This shower system a blend of modern outlook and fabulous showering experience. If you already have a gold finish in your bath fixtures, it makes perfect sense to invest in a gold shower system. Enhance your modern bathroom with the Leonardo Thermostatic Shower Set, which comes complete with the Square wall mount shower head, six square body jets, and the thermostatic dual shower valve. Its rainfall effect experience makes showering experience more soothing and relaxing. Its optimum design and innovative technology allow for voluminous soft droplets to make your showering experience a fun one. Constructed from solid brass and stainless steel with a high-quality gold finish, the thermostatic shower valve features stylish yet easy to use handles that control the flow and temperature of the water and a thermostatic diverter that allows you to switch between the fixed head, hand shower or the body jets.

Leonardo Gold Finish Rainfall Waterfall Shower System Set Features:

  • Brand Name: BathSelect
  • Model Number: BST077-GOLD
  • Showerhead Length: 22"
  • Showerhead Width: 10"
  • Material: Stainless Steel
  • Finish: Gold
  • Body Spray: Set of 6 body sprays 34 Nozzles
  • Controller: Thermostatic Dual Handle
  • Showerhead Style: Rain Fall & Water Fall Showerhead
  • Mount Method: Wall Mount
  • Connection: 1/2" US standard
Leonardo Gold Finish Rainfall Waterfall Shower System Set
BathSelectฎ Manufacturer Warranty Information
  • Before you begin, please read the installation instructions below. Observe all local building and safety codes.
  • Unpack and inspect the product for any shipping damages. If you find damages, do not install.
  • Please note all showers must be installed by a professional and certified plumber otherwise warranty might be voided.



1. Open the top cover and drill according to the marked position.

  • Mark by the position of the four holes.
  • Take care to avoid wires and pipes to prevent damage.
  • Be sure to confirm that the four holes are on the same horizontal line.

2. Two inlet fittings are connected to the pipe joint of the wall; then the nut, expansion screw, and inlet pipe are connected.

3. Reinstall the top cover.

Hand-Held Shower Instructions






5. Hole Locations For Wall Mount
Remove Front Cover (5A) from Wall Mount (5B). Use Wall Mount Screw Holes (5C) to place the desired location. Using a punch or awl, tap the screw hole locations. Holes must be vertically aligned.

7. Wall Mount Installation
Place Wall Mount (7A) into wall and inset Mounting Screws (7B) through Wall Mount Holes (7C) and tighten until Wall Mount (7A) is flush with the wall. Do Not Over Tighten! Insert Front Cover (7D) into Wall Mount (7A).





8. Drop Elbow & Hose Installation
Apply PTFE plumbers tape on both ends of Pipe Nipple (8A) (not included). Screw Pipe Nipple (8A) into the elbow inside the wall. The Pipe Nipple (8A) is to project 1/4” – 3/4” from the finished wall. Screw Drop Elbow (8B) onto Pipe Nipple (8A) and tighten until Drop Elbow (8B) is property positioned and flush to the finished wall.
Place Rubber Seal (8C) inside Hex Hose Fitting (8D). Connect Hex Hose Fitting (8D) into Drop Elbow Outlet (8E) by turning Hex Hose Fitting (8D).


9. Unit Start-Up
Turn on hot and cold water supplies, and check all connections for leaks.


10. Final Flushing
For final flushing, turn the valve on and allow water to run through the Hose (10A) for several minutes. Allow water to run for several minutes until all foreign matter clears the line.


11. Shower Arm Installation
Place Rubber Seal (11A) inside Tapered Hose Fitting (11B). Conned Hand Shower (11C) to Hose (11D) by turning Tapered Hose Fitting (118) clockwise.

Warning: Make sure Hand Shower (11C) is securely tightened to Hose (11D).




Body-Jet Installation



Multiple Bodyspray Installation
• Water Supply
• Nipple Mamelon Nipple
• Pressure Balancing Loop

1. Route the water supply lines.
2. If installing more than one bodyspray off the same supply line, construct a pressure balancing loop. Locate a tee along the loop at each bodyspray installation location.
3. Do not strap the pipes at this time.

Single Bodyspray Installation
• Nipple Mamelon Nipple
1. Route the water supply line.
2. Install an elbow to the end of the supply pipe at the bodyspray installation location.


Install the Plaster Guard
• Elbow (or Tee)
• Install the plaster guard

Set Piping Depth
Align mark with front of the stud face
• Thin Wall

Align mark with front of the stud face
• Standard Wall

Install the plaster guard. Push until the plaster guard is snug against the face of the elbow (or tee).



1. Install the water-resistant wall board.
2. Cut out a 4" (10.2 cm) to 4-1/4" (10.8 cm) square at each the installation location.
3. Install the finished wall material.


• Escutcheon
• Leak Shield
• Adapter
• Extension
• Socket Wrench With Bit
• Screw
• Waterway Passage

1. Insert the escutcheon into the rough opening. The double ribs of the leak shield should be facing up.
2. If the leak shield makes contact with the elbow: Enlarge the hole in the back of the leak shield to 1-1/4" (3.2 cm).
3. Thread the adapter onto the nipple using the provided 11 mm bit, 11 mm or 7/16" socket, extension and socket wrench. Use masking tape to hold the bit in place, as the bit could fall off and cause damage.
IMPORTANT! The escutcheon should sit loosely at this point. If it is tight against the wall, use a longer pipe nipple.
4. Align the groove in the waterway with the double ribs on the leak shield.
5. Press the waterway into place over the adapter. Secure the waterway to the adapter with the screw provided.
6. Verify that the escutcheon does not turn or shift.



With the ribs of the sprayhead facing up, install the sprayhead to the waterway.



With the ribs of the sprayhead facing up, install the sprayhead to the waterway.
