BathSelect VeloLink™ – Light Grey Motion

BathSelect VeloLink™ – Light Grey Motion

Alternative Views:





Availability: Project Pricing Available Request Quote
Product Code: BS8122LG
Request Quote

Description Technical Specs Extended Technical Information


BathSelect VeloLink Series Light Grey Motion Sensor Urinal Flush Valve

A flawless combination of efficiency and modern charm is the VeloLink™ Light Grey model and the advent of its rapid-response motion control has made it possible to gain a new level of performance in a commercial restroom. Its shiny surface is a classic, modern-day showroom that easily matches the newly updated interior styles, while at the same time providing a reliable, no-touch operation. Brass supported by plastic made a solid, unyielding structure that is apt for very busy areas, characterized by constant and heavy human traffic. The dual power option widens the choice of installation, thereby accommodating both the use of batteries - which means no power cuts - and the connection to the electricity grid - which means no interruptions. With the proper sensing range, the system guarantees that only the right amount of water will be used, thus creating the condition for better hygiene and less maintenance. At the same time, the water flow control helps to keep the pressure reasonable and the drain-free operation still effective without overusing the resource. Environmentally friendly technology is what strengthens the green initiatives, with water-saving performance as an accompanying factor for the long-term conservation activities. This fixture is accurate, durable, and visually pleasing all at once, giving it the status of a smart and modern upgrade that elevates restroom functionality not just in less difficult but also in more demanding commercial spaces.

Fast-Response Motion Flush

  • Brand Name: BathSelect®
  • Model Number: BS8122LG
  • Design Style: Contemporary
  • Product Type: Urinal Flush Valve
  • Flush Valve Type: Motion Sensor
  • Finish: Light Grey
  • Material: Brass, Plastic
  • Installation Type: Wall Mounted
  • Electronic Induction Type: DC & AC
  • Working Power: DC6V or AC220V optional
  • Sensing Distance: 13-26in (35-65cm)
  • Water Flow: 2-5L/flush time (0.3MPa)
  • Pressure Range: 15-100PSI
  • Working Water Pressure: 7.25-101.5PSI (0.05-0.7MPa)
  • Feature: Eco-Friendly, Water Saving
  • Mounting Diameter: G1/2" (DN15)
  • Inlet/Outlet diameter: G1/2" (DN15)
  • Static Power Consumption: <50uA
  • Dynamic Power Consumption: <2.5W
