BathSelect HydroIntel™ – White Motion

BathSelect HydroIntel™ – White Motion

Alternative Views:





Availability: Project Pricing Available Request Quote
Product Code: BS8113WH
Request Quote

Description Technical Specs Extended Technical Information


BathSelect HydroIntel White Automatic Sensor Urinal Flush Valve

By shedding modern restroom standards with brilliant light, the HydroIntel™ White edition has taken hands-free performance to a superior level through the use of motion technology that has been accurately adjusted to perfection. The product's bright and simple look creates a clean visual statement that marries perfectly with the current hotel and restaurant settings that require both functional and refined aesthetics. The construction of the product is done with high-quality ABS that ensures great durability but at the same time keeps the light profile that can be used in demanding commercial environments. The water flow can be customized according to the needs of the facility which enables the resort to be responsible in consuming water without losing effectiveness. The ability to use two power sources increases the options for installation and supports both the use of long-lasting batteries and stable AC connectivity. The responsive sensing area ensures smooth and contact-free interaction that is further supported by the rapid switching speed enhancing the overall user experience. This fixture is constructed to operate under extreme temperatures, high pressure, and heavy foot traffic conditions, thus always meeting the hygiene requirements while cutting down on the maintenance ordeal. Its bright surface and solid engineering draw it to be a good upgrade for any progressive area.

Intelligent Auto-Flush Technology

  • Brand Name: BathSelect®
  • Model Number: BS8113WH
  • Design Style: Contemporary
  • Product Type: Urinal Flush Valve
  • Flush Valve Type: Automatic Sensor
  • Finish: White
  • Material: High Quality ABS
  • Flush Time: Adjustable
  • Installation Type: Wall Mounted
  • Electronic Induction Type: DC & AC
  • Power Supply: DC:6V (4xAA alkaline batteries), AC 110V~220V
  • Flush Time: Adjustable
  • Application: Hotel
  • Treatment: Natural Surface
  • Sensing Distance: 60-70 cm (adjustable)
  • Water Temperature: 0.1-60 °C
  • Water Pressure: 0.2-0.7MPa
  • Environment Temperature: 0.1-45 °C
  • Switching Time: <0.7s
  • Operation Consumption: <60uA
  • Overall Power Consumption: <0.5W
  • Water Supply Pipe Size: DN15 (G1/2")
  • Front View Width: 5.31"
  • Front View Height: 5.31"
  • Side View Total Depth: 3.86"
  • Depth to Mounting Plate: 2.95"
  • Depth from Plate to Cover: 0.59"
