Bathselect Automatic Commercial Brushed Nickel Sensor Faucet (Available in Oil Rubbed Bronze Finish)

Bathselect automatic commercial motion sensor faucets for lavatory
Alternative Views:

Retail Price: $584.00
Sale Price: $538.69

Availability: Usually Ships in 5 to 10 Business Days
Product Code: BST514-N

Description Technical Specs Extended Technical Information

Bathselect Automatic Commercial Brushed Nickel Sensor Faucet designed for new and retrofit installations. Comes also in Chrome Finish or Oil Rubbed Bronze Finish

Plato Automatic Commercial Sensor Faucet D514 (Available in Oil Rubbed Bronze Finish)

Bathselect Automatic Commercial Brushed Nickel Sensor Faucet Product Description

The faucet is a motion electronically controlled faucets eliminate the need to touch or turn handles and the temperature and flow rate can be pre-set. Through the use of sensor beams the automatic faucet determines when an object is in front of it and automatically turns on the faucet. Since there is nothing to touch and nothing to reach for, an automatic faucet eliminates all of that cleaning and disinfecting that you do to try to maintain a hygienic surface.

  • Motion sensor with touchless operation
  • Sensitive Sensor with Infrared AI Smart-Chip
  • Factory set to 30-second Auto Shutoff (can be adjusted).
  • Water Pressure: 0.5 - 7.0 KGS/cm, 10 - 125 psi
  • Solid Brass Construction, Brushed Nickel Finish
  • Easy to Install - Instructions Included
  • Water resistant solenoid enclosure
  • Advanced energy saving design for long lasting battery life
  • Comes complete with Hoses & Accessories
  • Power Supply: AC110V And DC6V (batteries not included)
  • AC/DC power option.
  • ADA Compliant, commercial sensor faucet.
  • Easily can be installed in new or retrofit applications.
  • Usage: Commercial / Residential
  • Ideal for commercial use applications in public restrooms, restaurants, office building, public facilities, hospitals. Fits all standard US plumbing.

Fits all standard faucets.Uses 4AA Alkaline Batteries (purchase separately).Water Pressure: 0.5 - 7.0 KGS/cm, 10-125 psi.

Sensor Activated Faucet Special Features:Intelligent: with its micro-computer controlling its action, the faucet will self adjust its best detection zone as per the color and shape of lavatory Low power consumption: 4AA alkaline batteries can be used for 2 years at 200 cycles a day. Convenient to maintain: Built-in strainer prevents sundries from entering the solenoid valve and the strainer is easy to clean.

Comes Complete for easy installation.

Reduces the transfer of germs by preventing cross-contamination and re-contamination of germs and bacteria by not touching the faucets or handles.Cut down on water usage by minimizing waste of water while soaping, lathering, scrubbing and drying hands by eliminating unnecessary and unattended water flow.

Sensor Activated Faucet Special Features:

  • Durable Vandal-Resistant Brass Body; Ideal for Residential as well as commercial high use applications
  • Intelligent: with its micro-computer controlling its action, the faucet will self adjust its best detection zone as per the color and shape of lavatory
  • Flashing light indicator; a diagnostic indicators for power up, low battery, and solenoid function.
  • Meaning of the codes are described in the installation instructions.
  • Convenient to maintain; with built-in strainer to prevent sundries from entering the solenoid valve and the strainer is easy to clean
  • Faucet can be mount to any sink surface.
  • ADA Compliant.
  • Batteries life 8,000 cycles per month and with enough water pressure is approx 5 year service life of the batteries.
  • Adjustable sensing range; while the factory range is set about 4"to 5"from the sensor, it can be adjusted.
  • Diameter of inlet pipe: DN15
  • Diameter of outlet pipe: DN15
  • Water Pressure: 0.05Mpa - 0.7Mpa
  • Power and Voltage: DC.6V AC.220V - 50/60Hz
  • Power Consumption: 0.5MW <2W
  • Detection Zone: Factory set 25cm/10" (based on standard inductive board)
  • Ambient Temperature: 1 - 45 ℃ / 33.8 -113 °F
  • Degree of protection by enclosure: 1P56
BathSelect® Manufacturer Warranty Information
Installation Manual For Bathselect Commercial Brushed Nickel Sensor Faucet (Available in Oil Rubbed Bronze Finish)
Sensor Faucets Simple Installation Instructions FAQ-Sensor Faucet

Plato Sensor Faucet D514 Product Description: Electronic Sensor Faucet

  1. Water efficient,
  2. Hygienic,
  3. No-touch activation,
  4. Easy installation Durable,
  5. Solid DR-brass construction,
  6. Built-in filter,
  7. ADA compliant,
  8. Vandal resistant,
  9. Waterproof components,
  10. Complies with Food Premises Standard

Faucet Specification

  1. Body: Solid brass with Chrome
  2. Power: i>DC AA Alkaline Battery*4, ii>AC/DC alternately
  3. Working pressure: 0.5~7Bar
  4. Water supply pipe size: DN15 (G1/2")
  5. Ambient Tem. Range: 0.1~ 55 Celsius
  6. Sensing distance: adjustable 25cm (default 25cm)
  7. Sensing range setup: Digital
  8. Response time: 0.3 sec (default)
  9. Off Delay time: 1 sec (default)
  10. Pop-up drain: yes
  11. Fresh Battery Life Cycle: 500,000 on/off
  12. Low Battery Indicator: Red Led flash
  13. Weakness of Battery: Red Led on,
  14. Usage: Commercial / Residential
