Installation Instructions for Florence Wall Mount Brushed Nickel Shower Set
Florence Wall Mount Brushed Nickel Shower Set
The Florence wall mount Brushed Nickel shower finish is classy and elegant, that comes with a Ceramic Valve core and Brass Body. This shower set was specially designed for those people who like to keep things simple but still want to enjoy the pleasure of luxury. The set includes both an overhead shower and an adjustable handheld showerhead and a faucet, everything in a beautiful brushed nickel finish. It is wall-mount, very easy to install, either as a replacement or as a new fixture. It comes with a dual handle, making showering a most pleasurable experience. Only the best quality materials have been used – the body is made of solid brass, while the valve core material is ceramic, for long-lasting use. It comes complete with accessories and installation instructions.
BathSelect® Manufacturer Warranty Information
- Before you begin, please read the installation instructions below. Observe all local building and safety codes.
- Unpack and inspect the product for any shipping damages. If you find damages, do not install.
- Please note all showers must be installed by a professional and certified plumber otherwise warranty might be voided.
|
|
1. Brass Adapter
2. Faucet body
3.
Washers
4. Diverter
5. Shower bar
6. Hand shower holder
7. Shower bar bracket
8. Shower bar
9. Mounting base
10. Decoration cover
11. Rain shower head
12. Handheld shower
Step 1: Connect the brass adapter provided to the water supply line.
Step 2: Adjust lever and distance to fit the faucet body.
Step 3: Turn the water valve on for a while to let the dust and impurities out.
Step 4: Assemble the shower set.
Step 5: Place a pre-assembled shower in the wall to find the proper position and then mark the mounting hole that needs to be drilled.
Step 6: Drill a hole for the upper part shower bar bracket, screw it.
Step 7: Place the decoration cover to the brass adapters.
Step 8: Install the pre-assembled shower to the connections.
Step 9: Connect shower hose, handheld shower, and rain shower head.
|
