Installation Instructions for BathSelect Antique Shower Set
BathSelect Antique Style Shower-Head 8" with Faucet & Hand Shower
BathSelect traditional antique shower with faucet & hand-held shower. It has an antique color. This dual lever faucet comes with a durable easy-to-turn design & two sleek levers to adjust water pressure, which provides a desired smooth turning action while preventing unwanted dripping. This model is made for perfect bathroom design. This shower set has been made with premium grade lightweight.
BathSelect Antique Shower Set Specifications:
- Type: Classic Bathroom Shower Set
- Product Code: BS9512
- Product Brand: BathSelect
- Number of Handles: Dual
- Installation Mount: Wall Mount
- Installation Type: US Standard
- Fixed Support: Yes
- Core Material: Ceramic
- Size: 8"
- Customize: Yes
- Material: Brass
- Color: Antique Brass
- Number of holes: Dual
- Connection: G 1/2
- Surface Finish: Brass
- Hot & Cold Water: Yes
- Surface Treatment: Antique
- Handle Feature: Dual Handles Dual Control Bathroom Shower
- Product Dimension: 21.65 x 13.78 x 7.87 inches
|
|
BathSelect® Manufacturer Warranty Information
- Before you begin, please read the installation instructions below. Observe all local building and safety codes.
- Unpack and inspect the product for any shipping damages. If you find damages, do not install.
- Please note all showers must be installed by a professional and certified plumber otherwise warranty might be voided
1. Brass Adapter
2. Faucet body
3.
Washers
4. Diverter
5. Shower bar
6. Hand shower holder
7. Shower bar bracket
8. Shower bar
9. Mounting base
10. Decoration cover
11. Rain shower head
12. Handheld shower
Step 1: Connect the brass adapter provided to the water supply line.
Step 2: Adjust lever and distance to fit the faucet body.
Step 3: Turn the water valve on for a while to let the dust and impurities out.
Step 4: Assemble the shower set.
Step 5: Place a pre-assembled shower in the wall to find the proper position and then mark the mounting hole that needs to be drilled.
Step 6: Drill a hole for the upper part shower bar bracket, screw it.
Step 7: Place the decoration cover to the brass adapters.
Step 8: Install the pre-assembled shower to the connections.
Step 9: Connect shower hose, handheld shower, and rain shower head.
|
