Bravat Wall Mount Light Oil Rubbed Bronze Shower Set With Thermostatic Mixer Valve 3-Way Concealed

The Bravat Light Oil Rubbed Bronze Shower Set With Mixer Valve 3-Way Concealed Wall Mount is one of the most trendiest finishes across decor styles in the bathroom. It has a contemporary style with a beautiful Light Oil Rubbed Bronze finish. Turn on the fun in your shower and experience the true feeling of rain, as well as SPA body massage spray, relieving fatigue and stress just by turning on the water in a high-pressure bathroom head shower with 360° 6 adjustable body spray jets and a hand shower.

Bravat Light Oil Rubbed Bronze Shower Valve Mixer 3-Way Concealed Wall Mounted Features:

Brand Name: BathSelect

Model Number: BS1058

Type: Shower Set & Shower Mixer

Style: Contemporary

Type: Fixed Support Type

Surface Finish: Light Oil Rubbed Bronze

Installation Type: Wall Mount

Number of Jets: Four

Control Type: Single Holder Dual Control

Size: 7.91"-11.85" (201-300mm)

Surface Treatment: Polished

Valve Core Material: Ceramic

Bath Shower Type: In-Wall Shower Mixer

Valve Type: Ceramic Valve

Faucet Handle Material: Zinc Alloy

Mixer Body Material: Brass

Valve Included: Yes

Embedment Depth: 2.16" (55mm)

Valve Panel Dimension: 6.29"x6.29" (160x160mm)

Connector: G1/2"B (Standard)

Bravat Wall Mount Light Oil Rubbed Bronze Shower Set With Thermostatic Valve Mixer 3-Way Concealed

BathSelect® Manufacturer Warranty Information

Before you begin, please read the installation instructions below. Observe all local building and safety codes.
Unpack and inspect the product for any shipping damages. If you find damages, do not install.
Please note all showers must be installed by a professional and certified plumber otherwise warranty may be voided

shower

Shower Head Installation

	shower	Shower Head Parts Included: Wall Mounting Arm Locking nut Wall trim Shower arm Showerhead Fixing screws and wall plugs (not shown)	shower
Step 1		Step 2		Step 3
Step 4		Step 5		Step 6

Shower Body Jets Installation Instructions

Step 1

Set the decorative cover on the body jet.

shower

Step 2

Roll the raw material belt in the thread screws.

shower

Step 3

Use a wrench to tighten 6 body jets on the water outlet holes in a clockwise direction.

Thermostatic Mixer

Step 1

mixer

Step 2

mixer

Step 3

1) Fix the shower valve into the wall with screws. Use a level to ensure that the valve is straight and level. (Important: Flush the water supply pipes to remove any dirt and debris before installing the valve body)

2) Wrap Teflon tape around the pipe thread. Connect hot and cold water supply lines and all the in-wall pipes(not included) as desired to the valve. Turn on the water supply and open the cartridge to check for leaks. Then, put on the protective cover.

3) Remove the protective cover when the wall finished wall is completed. Install escutcheon onto the shower valve and press it against the finished wall. Then, install the handle and diverter knob to the valve and tighten set screws with the Allen key and put on the indication button.

Hand-Held Shower Installation Instructions
