Touchless Systems Guide — Large-Scale Implementation (Airports, Towers, Hubs)
Contractor & Architect Guide
Universal Touchless Systems — Field-Ready Guide
Practical, engineering-ready topics for very large facilities: airports, office towers, transit hubs, and stadiums — with specs, videos, and downloads.
♿ ADA
💧 WaterSense
🔥 Anti-Scald
🌿 LEED / WELL
Working Videos
These embeds are live. Replace with your own IDs anytime.
VIDEO
Sensor Faucet + Dryer
Wash + dry in one station; ideal for airports and stadiums.
Product Page
VIDEO
LED Showers with Cues
Hydro-powered LEDs indicate temperature for safer, inclusive use.
Product Page
VIDEO
Digital Thermostatic Showers
Stable temps and premium controls for VIP and wellness spaces.
Product Page
Large-Scale Touchless Implementation — Topics
Scroll to the end for the compact field-ready guide.
Catalog Shortcuts
High-resolution photos; replace with your own project shots if desired.
Case Studies & Gallery
High-resolution, realistic photography that matches the use cases.
Airport Concourse
High throughput sinks with integrated dryers improve flow and reduce slip risk.
Luxury Hotel
LED showers with thermostatic mixing deliver predictable comfort for VIP suites.
University Facility
Durable finishes and vandal-resistant mounting for high-traffic campus buildings.
Downloads & Libraries
Key references and help centers for design, installation, and O&M.
Revit / BIM Library (Architects)
Download families and BIM objects for coordination and submittals.
Open BIM Library
Commercial Sensor Faucet Install
How-to guides and tips for reliable sensor faucet commissioning.
Open Guides
Warranty & Support (O&M)
Policies, coverage, and service contacts for planning O&M.
View Warranty
Large-Scale Touchless Implementation — Topics & Guidance
Curated, engineering-focused topics tailored for heavy commercial use. (Optimized images)
Hardware Hardening
Faucets & Dispensers for Heavy Duty
316 SS or DZR brass bodies; PVD finishes with anti-fingerprint.
Thermostatic mixing (ASSE 1070/1017), 0.35–0.5 gpm options.
ToF sensing, IP65+ electronics, locking M8/M12 connectors.
Soap at Scale
Multifeed Soap Systems
5–10 L reservoir feeding 6–8 heads; peristaltic pumps.
Low-level & leak sensors; auto-purge; 80–100 μm inline filter.
Viscosity 1–3000 cP (liquid to foam concentrates).
BMS & Telemetry
Controls, Gateways & KPIs
BACnet/IP, Modbus TCP, or MQTT to cloud.
Usage, faults, temps, battery/AC status, soap levels.
Edge rules: lockout bursts; night-mode dwell increase.
Compliance
Hygiene, Safety & Standards
NSF/ANSI 61 & 372, ADA, WaterSense eligible flows.
Legionella flush and thermal disinfection schedules.
IK10 plates, concealed fixings, tamper-proof software.
Sustainability
LEED / WELL Support
Low-flow documentation; EPD/HPD availability.
Auto-learn patterns to optimize range and dwell.
Leak and anomaly detection across zones.
Design & Installation
Hydraulics, Electrical & Mounting
60–80 psi regulation, shock arrestors, hot recirc loops.
Labeled circuits; PoE/low-voltage raceways; gateways per 25–50 fixtures.
Reinforced backers; ADA heights; seismic/freeze provisions.
Operations
Maintenance Model & SLAs
Q3: strainers/aerators, firmware, sensor self-test.
Annual: seals refresh, ToF re-baseline, thermal validation.
Spare pool 5–10%; target uptime ≥99.7%.
Security
Device & Network Security
Signed firmware, secure boot, TLS 1.2+.
RBAC for config; VLAN & cert-based onboarding.
Offline-first fallbacks for critical functions.
Sizing
Airport/Transit Quick Sizing
1 lav per 40–60 pax/hour at gate clusters.
Soap stock ≈ 1.2× faucet activations (foam).
600 mm center spacing; troughs to reduce queues.
Final Field-Ready Guide (Copy into RFP / SOP)
Specify 316 SS/DZR brass; PVD finish; IK10 plates; concealed fixings.
ToF sensors; <200 ms; >100k lux immunity; IP65+ electronics.
0.35/0.5 gpm laminar; ASSE 1070/1017 mixing; cold-fail.
200 μm Y-strainer; check valves; locking M8/M12 connectors.
100–240 VAC primary; battery failover ≥400k activations; optional PoE.
Telemetry: usage, faults, temps, soap level via BACnet/IP/Modbus/MQTT.
Auto-purge & thermal disinfection; audit logs; tamper-proof settings.
Soap multifeed 5–10 L; 6–8 heads; peristaltic pump; leak & level sensors.
Docs: EPD/HPD, BIM (Revit), O&M manuals, 1-page SOP cards.
