Dark Oil Rubbed Bronze Square Shower Set Installation Instructions

Bravat Wall Mount Dark Oil Rubbed Bronze Square Shower Set With Thermostatic Mixer Valve Concealed

The Bravat Dark Oil Rubbed Bronze Square Shower Set With Valve Mixer Concealed Wall Mount is one of the most trendiest finishes across decor styles in the bathroom. It has a contemporary style with a beautiful Dark Oil Rubbed Bronze finish. Turn on the fun in your shower and experience the true feeling of rain, as well as SPA body massage spray, relieving fatigue and stress just by turning on the water in a high-pressure bathroom head shower with 360° 6 adjustable body spray jets and a hand shower.
Bravat Dark Oil Rubbed Bronze Shower Valve Mixer Concealed Wall Mounted Features:
  • Brand Name: BathSelect
  • Model Number: BS1057
  • Type: Shower Set & Shower Mixer
  • Style: Contemporary
  • Type: Fixed Support Type
  • Surface Finish: Dark Oil Rubbed Bronze
  • Installation Type: Wall Mount
  • Control Type: Single Holder Dual Control
  • Size: 7.91"-11.85" (201-300mm)
  • Surface Treatment: Polished
  • Valve Core Material: Ceramic
  • Bath Shower Type: In-Wall Shower Mixer
  • Valve Type: Ceramic Valve
  • Faucet Handle Material: Zinc Alloy
  • Mixer Body Material: Brass
  • Valve Included: Yes
  • Embedment Depth: 2.16" (55mm)
  • Valve Panel Dimension: 6.29"x6.29" (160x160mm)
  • Connector: G1/2"B (Standard)
  • Bravat Wall Mounted Dark Oil Rubbed Bronze Square Shower Set With Thermostatic Valve Mixer Concealed
    BathSelect® Manufacturer Warranty Information
    • Before you begin, please read the installation instructions below. Observe all local building and safety codes.
    • Unpack and inspect the product for any shipping damages. If you find damages, do not install.
    • Please note all showers must be installed by a professional and certified plumber otherwise warranty may be voided

    shower shower

    Shower Head Installation


    Shower Head Parts Included:
    • Wall Mounting Arm
    • Locking nut
    • Wall trim
    • Shower arm
    • Showerhead
    • Fixing screws and wall plugs (not shown)

    shower
    shower
    Step 1

    Step 2

    Step 3

    Step 4

    Step 5

    Step 6


    • Use your hands counter clockwise to unscrew the old showerhead and removed it.
    • Take out the showerhead, make sure the shower filter is placed in the connector.
    • Ensure the showerhead full horizontal alignment wall mounted shower arm thread.
    • Use your hands clockwise to tighten showerhead.
    Thermostatic Mixer Valve

    Step 1

    mixer Step 2


    mixer Step 3



    1) Fix the shower valve into the wall with screws. Use a level to ensure that the valve is straight and level. (Important: Flush the water supply pipes to remove any dirt and debris before installing the valve body)
    2) Wrap Teflon tape around the pipe thread. Connect hot and cold water supply lines and all the in-wall pipes(not included) as desired to the valve. Turn on the water supply and open the cartridge to check for leaks. Then, put on the protective cover.
    3) Remove the protective cover when the wall finished wall is completed. Install escutcheon onto the shower valve and press it against the finished wall. Then, install the handle and diverter knob to the valve and tighten set screws with the Allen key and put on the indication button.

    Hand-Held Shower Installation Instructions


    Step 1

    shower Step 2

    Step 3

    Step 4
