Installation Instructions for Briano MultiColor Water Powered Shower Solid Brass Built-in Mixer

The Briano Contemporary Brass Square Multi Color LED Rain Shower Head with Solid Brass Mixer

Turn on the fun in your shower just by turning on the water, the LED lights will automatically light up and set the mood. They will even change colors automatically based on the water temperature. All this with no batteries, everything is self-powered by a built in dynamo that takes advantage of the water pressure to create the energy to light the bulbs.

Briano MultiColor Water Powered Shower Solid Brass Built in Mixer Features:

  • Brand Name: BathSelect
  • Model Number: BT013-1
  • Shower Head Function: Waterfall and Rainfall (can work separately)
  • Shower Head capability: powers LED light using built-in dynamo
  • LED Light Function: Turn on when water pressure is turned on
  • Light will dim and brighten depending on pressure.
  • The flow rate is 2.5 GPM
  • Material: Solid Brass
  • Finish: Polished Chrome
  • Showerhead Height (thickness): 0.33
  • Showerhead Width: Available in 8", 10", 12", or 16"
  • Showerhead Length: Available in 8", 10", 12", or 16"
  • LED Power Source: Water Flow
  • LED Color: Blue, Green, Red
  • Showerhead Style: Contemporary Rain Shower
  • Mount Method: Wall or Ceiling Mount
  • Connection: 1/2" US standard (included)
  • Shower Arm: Included
Briano MultiColor Water Powered Shower Solid Brass Built in Mixer

BathSelect® Manufacturer Warranty Information

Before you begin, please read the installation instructions below. Observe all local building and safety codes.

  • Unpack and inspect the product for any shipping damages. If you find damages, do not install.
  • Please note all showers must be installed by a processional and certified plumber otherwise warranty might be voided









Shower Head Installation






No tools required, ½ connector fits standard sized shower plumbing.


  1. Use your hands counter clockwise to unscrew the old showerhead and removed it.
  2. Take out the showerhead, make sure the shower filter is placed in the connector.
  3. Ensure the showerhead full horizontal alignment wall mounted shower arm thread.
  4. Use your hands clockwise to tighten showerhead.




Wall-mounted-shower-head
1. Install the valve body. Wrap the threaded portion of the joints in Teflon tape and connect the water inlet and outlet.

2. Put the protective cover on the valve body and finish the shower wall.
Wall-mounted-shower-head

  1. When the finished wall is complete, remove the protective cover.
  1. Install the escutcheon, and handle it. Tighten the set screw with an Allen wrench to secure.
  1. Attach the shower arm escutcheon to the shower arm. Wrap the threaded portions of the shower arm with Teflon tape and connect the arm to the shower inlet. Adjust the direction of the water flow as needed. Attach the rainfall showerhead to the shower arm.
