Shower Rainfall Massage Shower Panel

Luna Shower Panel Rainfall Massage Jets Waterfall Shower Set - 304 Stainless Steel


This Luna Shower Rainfall Massage Shower Panel system is a multifunctional shower panel that offers everything needed for a delightful shower experience. Immerse yourself in a truly relaxing shower experience and enjoy the modern style of this beautifully designed shower panel.Our shower panels are very easy to install and the reciprocal of this means that at the end of their life, they can also be easily uninstalled and materials recovered for recycling. It comes super seal technology inside, capable of delivering superior performance with a solid construction for long durability that will upgrade your bathroom with a modern and cool look for a long period of time.

Black Bathroom Shower Panel Features:
Type Wall Mount Shower Panel
Cold/Hot Water Control Type Single Holder Dual Control
Size 5.15" - 7.87" (131-200mm)
Type Fixed Support Type
Surface Finish Stainless Steel
Installation Type Wall Mount
Surface Treatment Chrome
Materail Stainless Steel/Brass
Be Used To Bathroom/Hotel/Spa
Brand Name Luna Shower
Style Contemporary
Number of Handle Single Handle
Valve Core Material Ceramic
Bath & Shower Faucet Type Shower Panels
Model Number: 6124BS Black
Color Black
Install Wall-Mount
Flow rate 2.5 GPM
Luna Shower Rainfall Massage Shower Panel
ujia-10026-black-bathroom-shower-panel-massage ujia-10026-black-bathroom-shower-panel-jets ujia-10026-black-bathroom-shower-panel-shower

ujia-10026-black-bathroom-shower-panel-Waterfall ujia-10026-black-bathroom-shower-panel-stainless ujia-10026-black-bathroom-shower-panel-steel

BathSelect® Manufacturer Warranty Information







  1. n order to install this shower panel, a simple understanding of plumbing techniques will be necessary. Please contact a professional plumber if you are unfamiliar with plumbing techniques or require assistance.
  2. Separate cold and hot water supply lines. This shower panel replaces any mixing valve you are currently using.
  3. Remove the shower panel and locate the position of the mounting brackets. Take measurements and then transfer those brackets to the location of the wall. Mark the center point of the location of the mounting brackets.
  4. Using a drill, attach wall mounting brackets with the included hardware. An extra set of hands may be required for the following steps. Lift and locate the hot and cold water lines on the shower panel.
  5. Connect the hot and cold water supply lines to the flexible hoses. Be sure to use the included washers. It is recommended a 3/8″ right angle connection be installed to better route the flexible hoses.
  6. Once connected, lift the entire shower panel and hook it to the wall using the mount brackets. There are two types of mounting brackets used for our shower panels.
  7. Check if the unit is leveled. Test out all shower functions including the water temperature to finish the installation. If your water temperature is either too hot or too cold, please check the hot and cold water lines. The connection many by reversed (Cold and hot).
  8. Complete the installation by using a silicone sealant around the perimeter of the shower panel. Your installation is now complete. Sintra Stainless Steel Black Shower Panel System with Rainfall Shower & Body Massage Jets
