Installation Instruction For BathSelect 10 inches Wall Mounted LED shower set

10 inches Wall Mounted digital thermostatic shower Temperature display LED shower set

Digital shower specifics

  • Type: Bath & Shower Faucets,shower set
  • Brand Name: FontanaShowers
  • Cold/Hot Water Control Type: Auto-
    Thermostat Control
  • Style: Contemporary
  • Size: (7.91"-11.11") 201-300mm
  • Number of Handle: Single Handle
  • Surface Treatment: Polished
  • Type: Fixed Rotatable Type
  • Valve Core Material: Ceramic
  • Surface Finish: Chrome
  • Bath & Shower Faucet Type: Shower Sets
  • Feature: Thermostatic Faucets, LED Light
  • Installation Type: Wall Mounted
  • Model Number: BS10WD
  • Size: (10"*10"*0.31") 254*254*8mm
  • Surface: chrome
  • Material: brasS

Shower Description:

10 inches Wall Mounted digital thermostatic shower Temperature display LED shower set

  1. brass chrome plated
  2. 2542548mm

led shower head:

  1. A. When the water temperature is <29c, Blue will show automatically;
  2. When the water temperature is between 30c~39c,Green will show automatically
  3. When the water temperature is between 40c~49c, Red color will show automatically;
  4. When the water temperature is >53c, RED color will flash automatically.
BathSelect 10 inches Wall Mounted digital thermostatic shower Temperature display LED shower set10 inches Wall Mounted digital thermostatic shower Temperature display LED shower set

BathSelect® Manufacturer Warranty Information

  • Unit Type: Piece
  • Package Weight: 32.000kg (70.55lbs.)
  • Package Size: 74cm x 42cm x 92cm (29.13in x 16.54in x 36.22in)
10 inches Wall Mounted digital thermostatic shower Temperature display LED shower set - Packaging Details10 inches Wall Mounted digital thermostatic shower Temperature display LED shower set - led shower head10 inches Wall Mounted digital thermostatic shower Temperature display LED shower set10 inches Wall Mounted digital thermostatic shower Temperature display LED shower set - brass chrome plated10 inches Wall Mounted digital thermostatic shower Temperature display LED shower set
  • Before you begin, please read the installation instructions below. Observe all local building and safety codes.
  • Unpack and inspect the product for any shipping damages. If you find damages, do not install.
  • Please note all showers must be installed by a professional and certified plumber otherwise warranty might be voided



No tools required, ½ connector fits standard sized shower plumbing.


  1. Use your hands counter clockwise to unscrew the old showerhead and removed it.
  2. Take out the showerhead, make sure the shower filter is placed in the connector.
  3. Ensure the showerhead full horizontal alignment wall mounted shower arm thread.
  4. Use your hands clockwise to tighten showerhead.


Hand-Held Shower Instructions






5. Hole Locations For Wall Mount
Remove Front Cover (5A) from Wall Mount (5B). Use Wall Mount Screw Holes (5C) to place the desired location. Using a punch or awl, tap the screw hole locations. Holes must be vertically aligned.

7. Wall Mount Installation
Place Wall Mount (7A) into wall and inset Mounting Screws (7B) through Wall Mount Holes (7C) and tighten until Wall Mount (7A) is flush with the wall. Do Not Over Tighten! Insert Front Cover (7D) into Wall Mount (7A).





8. Drop Elbow & Hose Installation
Apply PTFE plumbers tape on both ends of Pipe Nipple (8A) (not included). Screw Pipe Nipple (8A) into the elbow inside the wall. The Pipe Nipple (8A) is to project 1/4” – 3/4” from the finished wall. Screw Drop Elbow (8B) onto Pipe Nipple (8A) and tighten until Drop Elbow (8B) is property positioned and flush to the finished wall.
Place Rubber Seal (8C) inside Hex Hose Fitting (8D). Connect Hex Hose Fitting (8D) into Drop Elbow Outlet (8E) by turning Hex Hose Fitting (8D).


9. Unit Start-Up
Turn on hot and cold water supplies, and check all connections for leaks.


10. Final Flushing
For final flushing, turn the valve on and allow water to run through the Hose (10A) for several minutes. Allow water to run for several minutes until all foreign matter clears the line.


11. Shower Arm Installation
Place Rubber Seal (11A) inside Tapered Hose Fitting (11B). Conned Hand Shower (11C) to Hose (11D) by turning Tapered Hose Fitting (118) clockwise.

Warning: Make sure Hand Shower (11C) is securely tightened to Hose (11D).
Digital Controller Installation

Operation
  • Fly-shuttle switch
  • Setting
  • Power on/off
  • LCD Display

Notice
1. The control panel is sensitive, when you install it, please avoid to let it face directly to the water from hand shower and the head shower because water will get it misoperation or lock the control panel.
2. The touch button is the best sensitive area.
3. The touch panel has water splash protection technology. When the system detects misoperation, no response, and need about 1 second to recover.

Function
1. Water TEMP adjust
2. Hand shower
3. Head Shower
4. Water flow adjust

Operation

1. Power on/off
Power on
After electrify, you can touch to make the system ON. When you hear buzzer sound, the fly-shuttle switch and the LCD panel would be lighting. Water TEMP and water flow will be the same as that you set last time. The cursor will be on the icon you using last time. The default working time is 60 minutes.

Power Off
When the system on, touch again to make the system OFF or the default working time is up, when you hear buzzer sound that means have close all the functions.

NOTE: (the background color of the fly-shuttle switch)
LED show blue color when TEMP below 33° C
LED show orange color when water TEMP between 34° C- 41° C
LED show red color when water TEMP over 41° C
