Brushed Gold Rainfall Round Shower Head And Hand Held Shower With Stress-Free Body Jet & Thermostatic Mixer Valve Enhance your bathroom with BathSelect Brushed Gold Rainfall Round Shower Head And Hand Held Shower With Stress-Free Body Jet & Thermostatic Mixer Valve which comes complete with the round shower head along with four square body jets and the thermostatic shower valve and a hand held shower. Its rainfall effect experience makes showering experience more soothing and relaxing. Its optimum design and innovative technology allow for voluminous soft droplets to make your showering experience a fun one. This shower set has been made with premium grade lightweight. Water flow capacity is around 10-60 L/min. The valve core material is a high quality of ceramic. It is ceiling wall shower head. Functions overview are Intelligence constant temperature, brass, large flow temperature water mixing, side spray, free switching spray, corrosion resistant. The BathSelect Brushed Gold Rainfall Round Shower Head And Hand Held Shower With Stress-Free Body Jet & Thermostatic Mixer Valve can experience the true feeling of rain, as well as SPA body massage spray, relieving fatigue and stress. It is your best choice, a choice to enjoy life. Brushed Gold Rainfall Round Shower Head And Hand Held Shower With Stress-Free Body Jet & Thermostatic Mixer Valve Specifications Type: Bathroom Shower Set Product Code: BST10234 Product Brand: BathSelect Installation Mount: Embedded Wall Mount Number of Jets: Four Installation Type: US Standard Fixed Support: Yes Style: Contemporary Color: Brushed Gold Shape: Round Material: Brass Customization : Yes Shower Water Flow: 10-60 L/min Valve Core Material: Ceramic Surface Finish: Brushed Function: Massage Body Jet BathSelect® Manufacturer Warranty Information Before you begin, please read the installation instructions below. Observe all local building and safety codes. Unpack and inspect the product for any shipping damages. If you find damages, do not install. Please note all showers must be installed by a professional and certified plumber otherwise warranty may be voided.

shower

Shower

	Shower Head Parts Included: Wall Mounting Arm Locking nut Wall trim Shower arm Showerhead Fixing screws and wall plugs (not shown)

Step 1:		Step 2:		Step 3:
Wall Mount Round Showerhead	Showerhead		Showerhead
Wall Mount Round Showerhead
Step 4:		Step 5:		Step 6:
Wall Mount Round Showerhead

Hand-Held Shower Installation Instructions

Step 1:		Step 2:		Step 3 & 4:
	Hand Held Shower		Hand Held Shower
Handheld Shower		Handheld Shower		Handheld Shower
Step 5:		Step 6 & 7:		Step 8:

2. HOLE LOCATIONS FOR WALL MOUNT

Remove Front Cover (A) from Wall Mount (B). Use Wall Mount Screw Holes (C) to place the desired location. Using a punch or awl, tap the screw hole locations.
Holes must be vertically aligned.

3. ANCHOR INSTALLATION

Drill two 1/4” dia. Holes (A). If installing into a studs drill two 1/8” dia. holes and do not use Anchors (B). Insert Anchors (B) into Holes (A) and tap flush with the wall.

4. WALL MOUNT INSTALLATION

Place Wall Mount (A) into wall and inset Mounting Screws (B) through Wall Mount Holes (C) and tighten until Wall Mount (A) is flush with the wall.
Do Not Over Tighten! Insert Front Cover (D) into Wall Mount (A)

5. DROP ELBOW & HOSE INSTALLATION

Apply PTFE plumbers tape on both ends of Pipe Nipple (A) (not included). Screw Pipe Nipple (A) into the elbow inside the wall.
The Pipe Nipple (A) is to project 1/4” – 3/4” from the finished wall. Screw Drop Elbow (B) onto Pipe Nipple (A) and tighten until Drop Elbow (B) is property positioned and flush to the finished wall.

Place Rubber Seal (C) inside Hex Hose Fitting (D). Connect Hex Hose Fitting (D) into Drop Elbow Outlet (E) by turning Hex Hose Fitting (D).

6. UNIT STARTUP

Turn on hot and cold water supplies, and check all connections for leaks.

7. FINAL FLUSHING

For final flushing, turn the valve on and allow water to run through the Hose (A) for several minutes.
Allow water to run for several minutes until all foreign matter clears the line.

8. SHOWER ARM INSTALLATION

Place Rubber Seal (A) inside Tapered Hose Fitting (B). Conned Hand Shower (C) to Hose (D) by turning Tapered Hose Fitting (B ) clockwise.
Warning: Make sure Hand Shower (C) is securely tightened to Hose (D).

Shower Body Jets Installation Instructions

Body Sprays Installation Instructions

Step 1:		Step 2:		Step 3:
	Body Sprays		Body Sprays
Set the decorative cover on the body jet.		Roll the raw material belt in the thread screws.		Use a wrench to tighten 6 body jets on the water outlet holes in a clockwise direction.

Mixer Installation Instructions

Thermostatic Shower Mixer Installation Instructions

Thermostatic Shower Mixer
Step 1:

	Parts List	Parts List: Shower Valve Hot Water Inlet Cold Water Inlet Diverter Knob Handle Set Screw Allen Key
