Installation Instructions for Recessed Color Changing Water Powered Led Shower Head

Recessed Color Changing LED Rain Shower Head

Turn on the fun in your shower just by turning on the water, the LED lights will automatically light up and set the mood. They will even change colors automatically based on the water temperature. All this with no batteries, everything is self-powered by a built in dynamo that takes advantage of the water pressure to create the energy to light the bulbs.

Features:

  • This high tech rain shower head powers the LED lights using a built in hidden dynamo
  • The lights will automatically turn on when water pressure is turned on
  • The lights will dim and brighten when you lower and raise the pressure so you can set the perfect mood, water and light
  • The shower head will automatically change colors according to the temperature of the water so you always know how the water will feel on your skin just by looking at it
  • Never be scalded again by entering a shower that is just too hot
  • The threading is universal so it will fit any standard shower head by simply unscrewing the old one by hand and attaching the new one.
  • Modern stylish design made to match or stand out from your other bathroom fixtures
  • High quality this modern shower head is made out of stainless steel, so it's made to last!
  • The flow rate is 2.5 GPM

Technical Specs

Material Stainless Steel
Finish Brushed Nickel, Mirror or Oil Rubbed Bronze
Style Contemporary Rain Shower head
Style Rain Fall and Water Fall
Shower head Width 16"
Shower head Length 28"
Warranty 1 Year Manufacturer Warranty
LED Power Source Water Flow
LED Color 3 Colors
Showerhead Style Recessed Contemporary Rain Shower
Mount Method Recessed
Connection 1/2" US standard
Mount MethodLED Power SourceRecessed Contemporary Rain Shower

https://www.bathselect.com/Recessed-Color-Changing-Water-Powered-Led-Shower-Head-Insta-s/482.htmRecessed Color Changing Water Powered Led Shower Head Installation Instructions

Shower


No.

Name

Quantity

No.

Name

Quantity

1.

Bracket

1

5.

Hexagon Wrench

1

2.

M10 Explosion
Screw

4

6.

Power

1

3.

Shower
Assembly

1

7.

Water Inlet
Connecting Pipe

4

4.

Lock Screws

4







1. Use a hexagon wrench to lose the lock screws then separate the showerhead assembly and bracket.



2. Dig 4 Ø10 holes on the ceiling according to the dimension of the screws.


3. Use a hammer to thwack the 4 screws into 4 holes.


4. Install the bracket on the expansion screws then use copper sleeve wrench to lock 4 screws.



5. Make sure all the water inlet pipe connected well without leaking before insert the power plug into the socket.


6. Fix the shower assembly on the bracket by turn the locking bolt.
