Installation Manual For Riviera LED Rectangular Shower Head

Riviera LED Rectangular Shower Head With Touch Panel Controller And Handheld Shower In Gold Finish

This is a Thermostatic Digital Multicolored LED shower that can be controlled using a remote control that pair with a digital pressure-balancing valve, which maintains your desired water temperature during pressure fluctuations. The LED rectangular wall mount shower head With touch panel controller & handheld shower can experience the true feeling of rain and waterfall together, as well as SPA body massage spray, relieving fatigue and stress. It is your best choice, a choice to enjoy life. This is a touch screen digital temperature control valve LED shower set. When the temperature exceeds 50 degrees will automatically stop working, preventing burns. LED lights can change color with different temperatures automatically.Turn on the fun in your shower just by turning on the water, the LED lights will automatically light up and set the mood. The thermostatic shower system is high flow shower valve, new technological coating layers electroplating to anti-rust, never get rust.ouch switch and multiple functions like shower time, water flow, screen, water temperature, master switch( temperature control, confirm key), set key(water temperature, flow), function key(hand shower, rainfall, waterfall). The threading is universal so it will fit any standard shower head by simply unscrewing the old one by hand and attaching the new one.It fits all US standard plumbing.

Riviera LED Rectangular Shower Head With Touch Panel Controller And Handheld Shower Features:
  • Brand Name: BathSelect
  • Model Number: BS9810
  • Type: Rectangle LED Shower Set
  • Style: Contemporary
  • Number of Handle: Single Handle
  • Bath & Shower Faucet Type: Wall mount
  • Cold/Hot Water Control Type: Single Holder Dual Control
  • Function: Digital controller
  • Material: Brass
  • Surface Treatment: Polished
  • Finish: Gold
  • Valve Core Material: Ceramic
  • Surface Finish: Stainless Steel Gold
  • Feature: LED Light,Metered Faucets,Cold and Hot mixer, Rain shower faucet , waterfall shower, touch panel control
  • Mixer Faucet: Hot and Cold
  • Riviera LED Rectangular Shower Head With Touch Panel Controller And Handheld Shower In Gold Finish
    BathSelect® Manufacturer Warranty Information
    . Open the top cover and drill according to the marked position.
    • Mark by the position of the four holes.
    • Take care to avoid wires and pipes to prevent damage.
    • Be sure to confirm that the four holes are on the same horizontal line.

    2. Two inlet fittings are connected to the pipe joint of the wall; then the nut, expansion screw, and inlet pipe are connected.

    3. Reinstall the top cover.

    Wall Mount Shower Head Installation

    Hand-Held Shower Instructions






    5. Hole Locations For Wall Mount
    Remove Front Cover (5A) from Wall Mount (5B). Use Wall Mount Screw Holes (5C) to place the desired location. Using a punch or awl, tap the screw hole locations. Holes must be vertically aligned.

    7. Wall Mount Installation
    Place Wall Mount (7A) into wall and inset Mounting Screws (7B) through Wall Mount Holes (7C) and tighten until Wall Mount (7A) is flush with the wall. Do Not Over Tighten! Insert Front Cover (7D) into Wall Mount (7A).





    8. Drop Elbow & Hose Installation
    Apply PTFE plumbers tape on both ends of Pipe Nipple (8A) (not included). Screw Pipe Nipple (8A) into the elbow inside the wall. The Pipe Nipple (8A) is to project 1/4” – 3/4” from the finished wall. Screw Drop Elbow (8B) onto Pipe Nipple (8A) and tighten until Drop Elbow (8B) is property positioned and flush to the finished wall.
    Place Rubber Seal (8C) inside Hex Hose Fitting (8D). Connect Hex Hose Fitting (8D) into Drop Elbow Outlet (8E) by turning Hex Hose Fitting (8D).


    9. Unit Start Up
    Turn on hot and cold water supplies, and check al connections for leaks.


    10. Final Flushing
    For final flushing, turn valve on and allow water to run through the Hose (10A) for several minutes. Allow water to run for several minutes until all foreign matter clears the line.


    11. Shower Arm Installation
    Place Rubber Seal (11A) inside Tapered Hose Fitting (11B). Conned Hand Shower (11C) to Hose (11D) by turning Tapered Hose Fitting (118) clockwise.

    Warning: Make sure Hand Shower (11C) is securely tightened to Hose (11D).
