Installation Instructions for Romo 22" Contemporary RGB Multi Color Shower Head

22 Inch Stainless Steel RGB Multi Color LED Rain Shower Set With this two-function waterfall and rain shower head you can turn on the fun in your shower just by turning on the water, the LED lights will automatically light up and set the mood. They will even change colors automatically based on the water temperature. All this with no batteries, everything is self-powered by a built in dynamo that takes advantage of the water pressure to create the energy to light the bulbs. Romo 22" Contemporary RGB Multi-Color Water Powered Led Shower Set Features: Brand Name: BathSelect Model Number: BT013-1 Shower Head Function: Waterfall and Rainfall (can work separately) Shower Head capability: powers LED light using built-in dynamo LED Light Function: Turn on when water pressure is turned on Light will dim and brighten depending on pressure. Shower Arm Type: Flex House Height: 1.1" Showerhead Length: 22" Width: 9" Material: Stainless Steel (304 US mirror) Showerhead Style: RGB Contemporary Rain Shower Valve Material: Solid Brass Finish: Chrome BathSelect® Manufacturer Warranty Information Before you begin, please read the installation instructions below. Observe all local building and safety codes. Unpack and inspect the product for any shipping damages. If you find damages, do not install. Please note all showers must be installed by a professional and certified plumber otherwise warranty might be voided

1. Open the top cover and drill according to the marked position.

• Mark by the position of the four holes.
• Take care to avoid wires and pipes to prevent damage.
• Be sure to confirm that the four holes are on the same horizontal line.

2. Two inlet fittings are connected to the pipe joint of the wall; then the nut, expansion screw, and inlet pipe are connected.

3. Reinstall the top cover.

Hand-Held Shower Instructions

5. Hole Locations For Wall Mount

Remove Front Cover (5A) from Wall Mount (5B). Use Wall Mount Screw Holes (5C) to place the desired location. Using a punch or awl, tap the screw hole locations. Holes must be vertically aligned.

7. Wall Mount Installation

Place Wall Mount (7A) into wall and inset Mounting Screws (7B) through Wall Mount Holes (7C) and tighten until Wall Mount (7A) is flush with the wall. Do Not Over Tighten! Insert Front Cover (7D) into Wall Mount (7A).

8. Drop Elbow & Hose Installation

Apply PTFE plumbers tape on both ends of Pipe Nipple (8A) (not included). Screw Pipe Nipple (8A) into the elbow inside the wall. The Pipe Nipple (8A) is to project 1/4” – 3/4” from the finished wall. Screw Drop Elbow (8B) onto Pipe Nipple (8A) and tighten until Drop Elbow (8B) is property positioned and flush to the finished wall.

Place Rubber Seal (8C) inside Hex Hose Fitting (8D). Connect Hex Hose Fitting (8D) into Drop Elbow Outlet (8E) by turning Hex Hose Fitting (8D).


9. Unit Start Up
Turn on hot and cold water supplies, and check al connections for leaks.

10. Final Flushing

For final flushing, turn valve on and allow water to run through the Hose (10A) for several minutes. Allow water to run for several minutes until all foreign matter clears the line.

11. Shower Arm Installation

Place Rubber Seal (11A) inside Tapered Hose Fitting (11B). Conned Hand Shower (11C) to Hose (11D) by turning Tapered Hose Fitting (118) clockwise.

Warning: Make sure Hand Shower (11C) is securely tightened to Hose (11D).
