BathSelect Dark Oil Rubbed Bronze Square Rainfall Shower Set Installation Instructions

BathSelect Dark Oil Rubbed Bronze Square Rainfall Shower Set with Handheld Shower

Enhance your modern bathroom with Dark Oil Rubbed Bronze Rainfall Shower Set with Handheld Shower, which comes complete with the square wall mount shower head along with four square body jets and the thermostatic triple shower valve and a hand held shower. Its rainfall effect experience makes showering experience more soothing and relaxing. Its optimum design and innovative technology allow for voluminous soft droplets to make your showering experience a fun one. Constructed from solid brass and stainless steel with a high-quality unique dark oil rubbed bronze finish, the thermostatic shower valve features stylish yet easy to use handles that control the flow and temperature of the water and a diverter that allows you to switch between the fixed head, hand shower or the body jets. Made from solid brass that looks sleek and modern but delivers a refreshing showering experience. The shower arm is wall-mount that has been made from brass. The square body jets enhance the overall showering experience and provide an invigorating massage effect, while the hand shower with adjustable slide bar allows for easier rinsing and cleaning. The flow rate is 2.5 GPM. Easy installation, comes with all standard accessories. It is designed to be lightweight, durable and corrosion-resistant and has an automatic anti-scald device.
Dark Oil Rubbed Bronze Square Rainfall Shower Set with Handheld Shower Product Features:
  • Brand Name: BathSelect
  • Model Number: BS1004
  • Finish: Dark Oil Rubbed Bronze
  • Brass Valve water pressure balance control
  • Standard plumbing connection-Shower panel unit is pre-plumbed
  • All functions work independently to ensure the proper water pressure
  • Ceramic Disc Technology
  • ½" NPT Inlets and outlets compatible with standard US plumbing connections
  • Pre-set maximum temperature 104ºf
  • The recommended pressure for best performance 2 to 75 psi
  • The flow rate is 2.5 GPM
BathSelect Dark Oil Rubbed Bronze Square Rainfall Shower Set With Handheld Shower
BathSelect® Manufacturer Warranty Information
  • Before you begin, please read the installation instructions below. Observe all local building and safety codes.
  • Unpack and inspect the product for any shipping damages. If you find damages, do not install.
  • Please note all showers must be installed by a professional and certified plumber otherwise warranty may be voided
shower shower

Shower Head Installation



Shower Head Parts Included:
  • Wall Mounting Arm
  • Locking nut
  • Wall trim
  • Shower arm
  • Showerhead
  • Fixing screws and wall plugs (not shown)
shower head shower head
Step 1
shower arm
shower Step 2
shower head
shower Step 3
Step 4

shower head
Step 5

shower head
Step 6

shower head

  • Use your hands counter clockwise to unscrew the old showerhead and removed it.
  • Take out the showerhead, make sure the shower filter is placed in the connector.
  • Ensure the showerhead full horizontal alignment wall mounted shower arm thread.
  • Use your hands clockwise to tighten showerhead.

Shower Body - Jets Installation Instructions





Step 1
Body jets
Set the decorative cover on the body jet.
Step 2
Body jet
Roll the raw material belt in the thread screws.
Step 3
body jet installation
Use a wrench to tighten 6 body jets on
the water outlet holes in a clockwise direction.

Thermostatic Mixer & Hand- Held Shower Installation Instructions




mixer
Mixer Shower system
Step 1
Hand held shower
Step 2
Hand held shower
Hand Step 3
Hand held shower

  • Open the closed cover of the shower holder and take out the screws.
  • Drill two holes size 0.2" (6mm) on the wall according to the hole position of the shower holder.
  • Use a hammer to break 2 plastic wall plug into two holes. Tighten the screws with the plastic wall plug and locking with the shower holder. Then install the closed cover.
  • Connect the shower hose with the water outlet connection part and hand shower. Plug the hand shower in the shower holder.
