Hole size on ceiling
1. Drawing the line on the ceiling according above specification
• Decorative Cover
• Pipe 1
2. Connect pipe 1 with decorative cover
3. Drill the holes on the ceiling according to above hole specification and install 4 pipes.
4. According right drawing, install four pipe 2 into pipe 1. Put the screw bolts through the hole on the side to lock pipe 2 with pipe 1.
5. As right drawing shown, install four pipe 2 on the head shower.
6. After fix the shower head on ceiling, connect the shower hose with 2 water inlet on the shower head back cover. The other end connect with the water outlet pipe in the wall.
5. As right drawing shown, install four pipe 2 on the head shower.
6. After fix the shower head on ceiling, connect the shower hose with 4 water inlet on the shower head back cover. The other end connect with the water outlet pipe in the wall.
Remarks: Ceiling mounted shower head come with fixing bar installation
1. Draw size on ceiling
2. Install fixing bar on ceiling
3. Install fixing bar on shower head
4. Put shower head bar on ceiling fixing bar.
The showerhead installation is now complete.Hand Held Shower Installation
Parts List
A. Hand Shower
B. Wall Anchors (x2)
C. Screws (x2)
D. Wall Bracket
E. Cap
F. Hose
G. Screen Washer
Place the screen washer in the end of the handshower hose. Screw the hose to the handshower.
If the flow of water becomes noticeably less, remove and clean the screen washer.
Scale Removal
The handshower incorporates the cleaning system. If scale deposits are noticed in the spray channels, turn the water on lightly and rub the spray channels with a finger or a sponge.
If scale deposits are noticed on the spray face, pour about 3/4" of a commercial scale remover into a shallow dish. Dilute the remover according to the label instructions.
Soak only the spray face in the solution for the amount of time specified on the label.
Rinse the handshower with clear water.
Reinstall the handshower. Turn on the water and al-low the handshower to flush for at least one minute.
